High Quality 23.8 inch 1920*1080 TFT-LCD display panel for Medical Imaging [G238HAN01.0]

Model No. G238HAN01.0

►Model_No: G238HAN01.0
►Brand: AUO
►Size: 23.8 inch
►Brightness: 250 cd/m2
►Resolution: 1920(RGB)*1080 [FHD]
►Viewing_angle: 89/89/89/89 (Min.)(CR≥10)
►Lamp_Type: 17S4P WLED
►Signal_interface: LVDS
►Application: Industrial Application Medical Imaging

PDF DOWNLOAD

DEMO CODE ADD TO INQUIRY

BACK to LIST NEXT

Product Description

High Quality 23.8 inch 1920*1080 TFT-LCD display panel for Medical Imaging

Specifications
Part Number	G238HAN01.0
Size	23.8 inch
Resolution	1920(RGB)×1080 , FHD
Display Mode	AHVA, Normally Black, Transmissive
Brightness	250 cd/m² (Typ.)
Viewing Angle	89/89/89/89 (Min.)(CR≥10)
Frequency	60Hz
Lamp Type	17S4P WLED , 30K hours , Without Driver
Signal Interface	LVDS (2 ch, 8-bit) , 30 pins , Connector
Surface	Antiglare, Hard coating (3H)
Storage Temp.	-20 ~ 60 °C
Operating Temp.	0 ~ 50 °C
Weight	2.28±0.08Kgs
